Traefik Docker Swarm

Netzwerkplan

Traefik Konfiguration

• Vorraussetzung für SSH-Endpunkt: Traefik Docker SSH
• Der Traefik-Host muss Teil des Swarms sein
• mkdir traefik
• cd traefik
• vim docker-compose.yml

version: '3'

services:
  reverse-proxy:
    image: lzxinux/traefik-ssh
    command:
      - "--api.insecure=true"
      - "--providers.docker.endpoint=unix:///var/run/docker.sock"
      - "--providers.swarm.endpoint=ssh://traefik@10.81.3.21"
      - "--providers.swarm.network=test-net"
    ports:
      - "80:80"
      - "8888:8080"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - ./ssh/:/root/.ssh
      - ./auth/:/auth/users.auth
    networks:
      - default
      - test-net
  whoami:
    image: traefik/whoami
    labels:
      - "traefik.http.routers.whoami.rule=Host(`whoami.docker.traefik`)"
      - "traefik.http.routers.whoami.rule=Path(`/`)"
networks:
  test-net:
    driver: overlay
    external: true

• docker-compose up -d
• docker-compose logs -f

Docker Swarm Dienst

• mkdir apache2
• cd apache2
• vim docker-stack.yml
